PROTAC® STRUCTURAL ACRYLIC ADHESIVES
Novachem offers the latest technology and most advanced structural adhesives available. Our Protac® range of Structural adhesives offers increased strength and flexibility while providing the next stage in structural load bearing capabilities on a range of substrates. Fixture times range from 45 seconds to 90 minutes depending on the grade and application requirements.
Protac® MMA Structural adhesives can withstand paint bake cycles, including powder coating and electron coating at typically 220°C – 230°C for up to 35 minutes with no loss of mechanical strength. The difference in viscosity and cure times enables manufacturers to choose the grade that best suits their production process and results in improved productivity and lower costs. No other grade range offers the combination of physical properties, ease of use and superior mechanical strengths for bonding engineered plastics, composites and metals.
Typical advantages of Protac® Structural Adhesives are:
- Stress distribution uniformed over a surface face
- Weight saving for light-weight construction
- Surface and texture of joined materials remain uniform
- Prevention of loss of pressure or liquids by sealed joints
- Reduced risk of corrosion when joining dissimilar material
Our Protac® Structural adhesive range offers superior strength in bonding Composites, Thermoplastics, Metals, and dissimilar substrates. Our range of structural acrylic adhesives has been engineered for industry sectors such as:
- Energy - wind turbine housing assemblies, wind blades, solar panels
- Transport - rail, buses, coaches, cars, trucks, aircraft
- Marine - yachts, liners, leisure boats, sails
- Construction - FRP facades and bridges, safety doors, acrylic signs
- Industrial - bonding metals, thermoplastics, thermosets, PMMA, ABS, PC and composite assemblies
Customised formulations can be developed to meet your specific application requirements, and a variety of packaging options are available. We offer our customers comprehensive technical assistance with their product applications, and product samples are available upon request.
|
Protac® Grade |
Packaging |
Colour |
Working Time mins |
Fixture Time |
Temp. °C |
Mix Ratio |
Application |
|
7300 |
50ml |
Natural |
5-8 |
10-12 |
-40 / +120 |
1:1 |
Structural adhesive with excellent adhesion to plastics and metals. Ideal for a wide range of manufacturing applications for dissimilar materials, substrates and surface types. |
|
7302 |
50ml |
Green |
2-3 |
5 |
-40 / +125 |
1:1 |
Very fast cure structural adhesive. Excellent adhesion to plastics and metals. Suitable for a wide range of manufacturing applications for dissimilar materials, substrates and surface types. |
|
7310 |
50ml |
Natural |
8-10 |
18-22 |
-40 / +120 |
1:1 |
High performance structural adhesive. Formulated to bond a wide variety of metal and plastic based substrates, dissimilar materials and surface types. |
| 7318 | 50ml 400ml |
Ultra White | 6-9 | 22-27 | -40 / +120 | 1:1 |
Ultra white formulation with excellent impact, peel and shear resistance. High strength, high elongation with excellent load distribution. Excellent low and high temperature properties. Room temperature cure with 6-9 minute working time. |
| g | g | g | g | g | g | g | g |
|
7411-CM |
50ml |
Clear |
30-75 secs |
3 |
-40 / +125 |
1:1 |
Clear metal and plastic structural acrylic adhesive. Toughened structural methacrylate adhesive specifically formulated for bonding wide variety of metals, thermoplastics, thermosets, PMMA, ABS, PC and composite assemblies. |
|
7411-CP |
50ml |
Clear |
1-2 |
3 |
-40 / +125 |
1:1 |
Clear metal and plastic structural acrylic adhesive. Toughened structural methacrylate adhesive specifically formulated for bonding wide variety of thermoplastics, thermosets, PMMA, ABS, PC and composite assemblies. |
| g | g | g | g | g | g | g | g |
| 7400 | 50ml 490ml |
Cream | 2-3 | 120-180 | -55 / +125 | 10:1 |
Formulated to bond low surface energy plastics including many grades of Polypropylene, Polyethylene, TPO, UHMWPE and Teflon without the use of a primer or other surface treatments. Excellent humidity and water resistance properties. |
| a | a | a | a | a | a | a | a |
| 7319 |
50ml |
Ultra White | 18-22 | 45-60 | -40 / +150 | 10:1 |
Ultra white formulation with excellent impact, peel and shear resistance. High strength, high elongation with excellent load distribution. Excellent low and high temperature properties. Room temperature cure with 18-22 minute working time. |
| 7480 |
50ml |
Natural Black |
10 | 15-30 | -40 / +200 | 10:1 |
Superior impact, peel and shear resistance. Excellent low and high temperature properties. Suitable for paint bake cycle applications up to 200°C with no loss of mechanical properties. Elongation 60%. Shore D75. |
| 7485 | 50ml 415ml |
Natural | 8 | 13 | -40 / +200 | 4:1 |
Suitable for paint bake cycle applications up to 200°C with no loss of mechanical properties. Combined at a 4:1 mix ratio, non sagging thixotropic formulation. Superior impact, peel and shear resistance. Excellent low and high temperature properties. Elongation 200%. Shore D55. |
| 7490 |
50ml |
White | 90 | 120 | -40 / +150 | 10:1 |
Long open time. Excellent impact, peel and shear resistance. Excellent low and high temperature properties. Ideal for bonding a wide variety of metals, glass, carbon fibre, thermoplastics, thermosets and composite assemblies. |
| g | g | g | g | g | g | g | g |
| 7430-5 |
50ml |
Natural |
2 | 5 | - 40 / +200 | 10:1 |
30% Elongation. Short 5 minute handling time. Excellent impact, peel and shear resistance. Excellent low and high temperature properties. Suitable for paint bake cycle applications up to 200°C with no loss of mechanical properties. |
| 7430-15 |
50ml |
Natural |
7 | 15 | - 40 / +200 | 10:1 |
30% Elongation. Medium 15 minute handling time. Excellent impact, peel and shear resistance. Excellent low and high temperature properties. Suitable for paint bake cycle applications up to 200°C with no loss of mechanical properties. |
| 7430-45 |
50ml |
Natural |
20 | 45 | - 40 / +200 | 10:1 |
30% Elongation. Long 45 minute handling time. Excellent impact, peel and shear resistance. Excellent low and high temperature properties. Suitable for paint bake cycle applications up to 200°C no loss of mechanical properties. |
| 7430-60 | 50ml 490ml |
Natural Black |
30 | 60 | - 40 / +200 | 10:1 |
30% Elongation. Long 60 minute handling time. Excellent impact, peel and shear resistance. Excellent low and high temperature properties. Suitable for paint bake cycle applications up to 200°C with no loss of mechanical properties. |
| g | g | ||||||
| 7415-5 |
50ml |
Natural | 2 | 5 | -40 / +150 | 10:1 |
150% Elongation. Short 5 minute handling time. Excellent impact, peel and shear resistance. High strength grade with excellent load distribution. Excellent low and high temperature properties. |
| 7415-15 |
50ml |
Natural | 7 | 15 | -40 / +150 | 10:1 |
150% Elongation. Medium 15 minute handling time. Excellent impact, peel and shear resistance. High strength grade with excellent load distribution. Excellent low and high temperature properties. |
| 7415-45 |
50ml |
Natural | 20 | 45 | -40 / +150 | 10:1 |
150% Elongation. Long 45 minute handling time. Excellent impact, peel and shear resistance. High strength grade with excellent load distribution. Excellent low and high temperature properties. |
| g | g | ||||||
| 7440-5 |
50ml |
Black | 2 | 5 | -40 / +150 | 10:1 |
300% Elongation. Short 5 minute handling time. Excellent impact, peel and shear resistance. High strength grade with excellent load distribution. Excellent low and high temperature properties. |
| 7440-15 |
50ml |
Black | 7 | 15 | -40 / +150 | 10:1 |
300% Elongation. Medium 15 minute handling time. Excellent impact, peel and shear resistance. High strength grade with excellent load distribution. Excellent low and high temperature properties. |
| 7440-45 |
50ml |
Black | 20 | 45 | -40 / +150 | 10:1 |
300% Elongation. Long 45 minute handling time. Excellent impact, peel and shear resistance. High strength grade with excellent load distribution. Excellent low and high temperature properties. |
